Silicones for Mold Making Applications

Silicones for Mold Making Applications provide a versatile, easy-to-use material with a long shelf life and fast cure time that can be controlled by adjusting the formulation. These materials are known to not harm surfaces and rarely need the use of a release aid.

NAME VINYL CONTENT VISCOSITY AVAILABLE DOWNLOAD
Andisil® VS 6 3.00 mmoles/gm 6 cSt Data Sheet
Andisil® VS 10 1.70 mmoles/gm 10 cSt Data Sheet
Andisil® VS 20 1.20 mmoles/gm 20 cSt Data Sheet
Andisil® VS 50 0.80 mmoles/gm 50 cSt Data Sheet
Andisil® VS 100 0.37 mmoles/gm 100 cSt Data Sheet
Andisil® VS 200 0.25 mmoles/gm 200 cSt Data Sheet
Andisil® VS 250 0.22 mmoles/gm 250 cSt Data Sheet
Andisil® VS 400 0.19 mmoles/gm 400 cSt Data Sheet
Andisil® VS 500 0.15 mmoles/gm 500 cSt Data Sheet
Andisil® VS 1,000 0.11 mmoles/gm 1,000 cSt Data Sheet
Andisil® VS 2,000 0.08 mmoles/gm 2,000 cSt Data Sheet
Andisil® VS 4,000 0.07 mmoles/gm 4,000 cSt Data Sheet
Andisil® VS 5,000 0.06 mmoles/gm 5,000 cSt Data Sheet
Andisil® VS 10,000 0.05 mmoles/gm 10,000 cSt Data Sheet
Andisil® VS 20,000 0.04 mmoles/gm 20,000 cSt Data Sheet
Andisil® VS 65,000 0.03 mmoles/gm 65,000 cP Data Sheet
Andisil® VS 80,000 0.024 mmoles/gm 80,000 cP Data Sheet
Andisil® VS 100,000 0.02 mmoles/gm 100,000 cP Data Sheet
Andisil® VS 165,000 0.015 mmoles/gm 165,000 cP Data Sheet
*These properties are not intended to be used as specifications but only as suggested characteristics
Also offered in EU compliant grades (< 0.1% D4-D6). Please inquire for more information.
NAME REFRACTIVE INDEX VISCOSITY VINYL CONTENT AVAILABLE DOWNLOAD
Andisil® VQM 0.6 1.406 600 cP 0.3 mmole/gm Data Sheet
Andisil® VQM 1 1.406 1,200 cP 0.24 mmoles/gm Data Sheet
Andisil® VQM 6 1.406 6,000 cP 0.22 mmoles/gm Data Sheet
Andisil® VQM 60 1.406 60,000 cP 0.20 mmoles/gm Data Sheet
Andisil® VQM 100 1.406 100,000 cP 0.52 mmoles/gm Data Sheet
Andisil® VQM 1040 1.406 15,000 cP 0.40 mmoles/gm Data Sheet
Andisil® VQM 2050 1.406 500 cP 1.1 mmoles/gm Data Sheet
*These properties are not intended to be used as specifications but only as suggested characteristics
NAME DESCRIPTION SiH CONTENT VISCOSITY AVAILABLE DOWNLOAD
Andisil® XL 1B SiH Functional 0.95 mmole/gm 100 cSt Data Sheet
Andisil® XL 10 SiH Functional 7.55 mmole/gm 45 cSt Data Sheet
Andisil® XL 11 SiH Functional 4.35 mmole/gm 45 cSt Data Sheet
Andisil® XL 12 SiH Functional 1.10 mmole/gm 500 cSt Data Sheet
Andisil® XL 13 SiH Functional 3.80 mmole/gm 100 cSt Data Sheet
Andisil® XL 17 SiH Functional 1.95 mmole/gm 50 cSt Data Sheet
*These properties are not intended to be used as specifications but only as suggested characteristics
Also offered in EU compliant grades (< 0.1% D4-D6). Please inquire for more information.
NAME DESCRIPTION SiH CONTENT VISCOSITY AVAILABLE DOWNLOAD
Andisil® XL 1340* SiH Functional 3.0 mmole/gm 50 cSt Data Sheet
Andisil® XL 1341* SiH Functional 4.2 mmole/gm 40 cSt Data Sheet
Andisil® XL 1342* SiH Functional 8.6 mmole/gm 50 cSt Data Sheet
* Random Pendant & Terminal Functional
**These properties are not intended to be used as specifications but only as suggested characteristics
NAME DESCRIPTION SiH CONTENT VISCOSITY AVAILABLE DOWNLOAD
Andisil® CE-4 Chain Extender Terminal SiH Functional 2.90 mmole/gm 4 cSt Data Sheet
Andisil® CE-13 Chain Extender Terminal SiH Functional 1.60 mmole/gm 14 cSt Data Sheet
Andisil® CE-500 Chain Extender Terminal SiH Functional 0.16 mmole/gm 500 cSt Data Sheet
*These properties are not intended to be used as specifications but only as suggested characteristics
Also offered in EU compliant grades (< 0.1% D4-D6). Please inquire for more information.
TYPE % PT DILUENT AVAILABLE DOWNLOAD
Karstedt 20.00% VTS Data Sheet
Karstedt 1 - 3.25% 200, 500, 1000 cSt vinyl polymer Data Sheet
Ashby’s Catalyst 2% Vinyl Cyclic Data Sheet
*These properties are not intended to be used as specifications but only as suggested characteristics
NAME % PT DESCRIPTION AVAILABLE DOWNLOAD
Andisil® 782 Catalyst 2.25 For use with high phenyl content (> 35% by wt) Si polymers Data Sheet
Andisil® 785 Catalyst 0.50 For use in high RI formulations
*These properties are not intended to be used as specifications but only as suggested characteristics
NAME CHEMICAL NAME CAS # AVAILABLE DOWNLOAD
Andisil® 1100 Silane Aminopropyltriethoxysilane 919-30-2 Data Sheet
Andisil® 1110 Silane Aminopropyltrimethoxysilane 13822-56-5 Data Sheet
Andisil® 1120 Silane Aminoethylaminopropyltrimethoxysilane (technical grade) 1760-24-3 Data Sheet
Andisil® 1122 Silane Aminoethylaminopropyltrimethoxysilane 1760-24-3 Data Sheet
Andisil® 1130 Silane Triamino-functional propyltrimethoxysilane 35141-30-1 Data Sheet
Andisil® 1170 Silane Bis(trimethoxysilylpropyl)amine 82985-35-1 Data Sheet
Andisil® 2100 Silane Aminopropylmethyldiethoxysilane 3179-76-8 Data Sheet
Andisil® 2120 Silane N-(2-Aminoethyl)-3-aminopropylmethyldimethoxysilane 3069-29-2 Data Sheet
Andisil® 6021 Silane Aminoethylaminopropyltriethoxysilane 5089-72-5 Data Sheet
*These properties are not intended to be used as specifications but only as suggested characteristics
NAME CHEMICAL NAME CAS # AVAILABLE DOWNLOAD
Andisil® 6123 Silane Phenyltriethoxysilane 780-69-8 Data Sheet
Andisil® 6124 Silane Phenyltrimethoxysilane 2996-92-1 Data Sheet
*These properties are not intended to be used as specifications but only as suggested characteristics
NAME CHEMICAL NAME CAS # AVAILABLE DOWNLOAD
Andisil® 151 Silane Vinyltriethoxysilane 78-08-0 Data Sheet
Andisil® 158 Silane Vinyltris(isopropenoxy)silane 15332-99-7 Data Sheet
Andisil® 171 Silane Vinyltrimethoxysilane 2768-02-7 Data Sheet
Andisil® 172 Silane Vinyltris(2-methoxyethoxy)silane 1067-53-4 Data Sheet
*These properties are not intended to be used as specifications but only as suggested characteristics
NAME DESCRIPTION CAS # AVAILABLE DOWNLOAD
Andiform C 100 Filled Silicone Vinyl-terminated Compound 68083-18-2 Data Sheet
Andiform C 106 Filled Silicone Vinyl-terminated Compound 68083-18-2 Data Sheet
Andiform C 300 Filled Silicone Vinyl-terminated Compound 68083-18-2 Data Sheet
Andiform C 1000 Filled Silicone Vinyl-terminated Compound 68083-18-2 Data Sheet
*These properties are not intended to be used as specifications but only as suggested characteristics
NAME DESCRIPTION CAS# AVAILABLE DOWNLOAD
Andisil® 2827-186L 1,3 Divinyl Tetramethyl Disiloxane 2627-95-4 Data Sheet
Andisil® MVC Methyl Vinyl Cyclics 2554-06-5 Data Sheet
*These properties are not intended to be used as specifications but only as suggested characteristics
NAME DESCRIPTION CAS # AVAILABLE DOWNLOADS
Andisil® HMDZ Hexamethyldisilazane 999-97-3 Data Sheet
*These properties are not intended to be used as specifications but only as suggested characteristics

For product samples, price quotes or SDS documentation, contact us.
